Dust Collector Filter Cages

Dust collector cages for all makes and models - Baghouse.comBaghouse.com manufactures a wide range dust collector cages to fit all baghouse makes and models. Whether to fit Baghouse.com dust collector filters, new installations, or aftermarket replacements, Baghouse.com dust collector cages will meet your needs.

Cage constructions typically consist of 10, 12 or 20 vertical wires. The horizontal ring spacing on the cage can be 4″, 6″ or 8″. If plenum height restrictions are a problem, two piece cages are available in popular “twist-lock” or “fingers” styles. For areas where moisture or acid corrosion present we can provide a range of materials, often galvanized steel or stainless steel. Top load baghouse cages are available with a T-flange, ring top or several styles of rolled flange tops. Cage diameters range from 4″ to 6 1/8″. Wire thickness ranges are; 9 gauge, 10 gauge and 11 gauge. Cages for bottom load baghouses are constructed with a split collar or split ring top. Cage diameters range from 4″ to 6 1/8″. Wire thickness ranges are 9 gauge, 10 gauge and 11 gauge.

Get pricing on your baghouse cages today! Call us at 800 351 6200 or email your request today!

For more efficient cleaning, Venturi are available for all diameter cages. Venturi come in 3″ to 6″ lengths. Venturi are made in a variety of materials including; aluminum, carbon steel, galvanized and stainless steel.

Our dust collector cages can be made to fit existing collectors from any baghouse manufactures such as Astek, Gencor, Flexkleen, Mikropul, Wheelabrator, etc.  We can also manufacture uncommon and specialized cage designs as required.

Learn more about baghouse cages on our blog

– Can I Reuse My Baghouse Cages When I Change my Filters?

Various dust collector filter cage styles and models

Common baghouse cage styles include rolled top (top load baghouses) and split collar (bottom load baghouses). Options include carbon steel, galvanized, stainless or epoxy coated. Cages also can have integral or drop in venturi for improved bag cleaning.

Materials/Finishes

  • Carbon Steel
  • 304 Stainless Steel
  • 316 Stainless Steel
  • Epoxy (High Temp <325°)
  • Galvanized Steel

Vertical Wires

  • 10, 12, and 20 most common
  • 5, 6, 8, 16 and 24 also available

Sizes

  • Common diameters: 4″ – 6-1/8″  (fits most baghouse OEMs)
  • Common lengths: 6′ – 12′ (shorter/longer lengths also available)

Options
Venturi

    • Aluminum, carbon steel, galvanized or stainless steel
    • 3″ – 6″ lengths
    • Attached (riveted) or drop-in/removable designs
  • Two-piece option
    • “Twist-lok” style (good for baghouses with low clearance)
    • “Fingers” style
  • Top load and bottom load dust collector cages
To receive more information about dust collector filter bag cages, or a free quote, please contact us today!

Two-Piece-Baghouse-Cage-Options-Diagram

Different dust collector cage designs from Baghouse.com.
